IC694DSM314 Module | GE – PACSystems RX3i Motion Mate Controller

GE Fanuc IC694DSM314 Motion Mate Module for RX3i SystemsThe IC694DSM314 from GE Fanuc delivers specialized motion control capabilities for PACSystems RX3i automation platforms. This optional accessory module provides advanced motion functionality for applications requiring precise positioning and synchronization. It extends system capabilities without requiring complete controller replacement.Technical Specifications & Performance DataBrand: GE FanucModel: IC694DSM314Module Type: Motion Mate ModulePower Requirements: 5V DC, 800 mA (4W) standaloneExtended Power: Additional 500 mA (2.5W) with external controllerCPU Compatibility: All RX3i CPU modulesControl Modes: Standard Mode and Follower ModeElectronic CAM: Supported for complex motion profilesHot Swap Capability: Not supported – requires power shutdownOperating Temperature: 0°C to 60°C industrial rangeMotion Control Capabilities & ModesThe IC694DSM314 provides standard motion control mode for basic applicationsIt enables follower mode operation for synchronized motion controlThis module supports electronic CAM functionality for complex profilesIt handles precise positioning tasks with high accuracy requirementsThe module manages synchronized multi-axis movements in automation systemsIt provides advanced motion profiling for specialized applicationsSystem Integration & CompatibilityThis motion module maintains compatibility with all RX3i CPUsIt installs in RX3i serial expansion racks for system expansionThe module operates in Series 90-30 expansion racks for legacy integrationIt functions within complete PLC system architectures with backplanes and I/OThis specialized module serves as an optional system enhancementIt provides motion-specific functionality for targeted applicationsInstallation & Safety RequirementsThis module does not support hot swapping under any circumstancesInstallation requires complete system power shutdown before handlingHot swapping can cause electrical arcing and system malfunctionsImproper handling may result in equipment damage or personal injuryIn hazardous environments, arcing could cause potentially explosive situationsAlways follow proper lockout/tagout procedures during installationPower Management & Electrical CharacteristicsThe module operates with 800 mA current draw at 5V DC standaloneIt consumes 4 watts of power during normal operationWith external controllers, it handles additional 500 mA load capacityExtended operation supports extra 2.5 watts power consumptionThe module requires stable 5V DC power supply from backplaneProper power budgeting is essential for reliable system operationApplication Specific ConsiderationsThis module serves as an optional accessory for specialized applicationsIt is not an essential component for basic PLC operationsThe module addresses specific motion control requirementsIt enhances systems needing advanced positioning capabilitiesThis solution provides cost-effective motion enhancement for existing systemsIt enables gradual system upgrades without complete replacementPackaging & Shipping InformationYour order includes one IC694DSM314 Motion Mate ModuleAll shipments include comprehensive 12-month warranty coverageWe provide worldwide shipping via FedEx, UPS, and DHL servicesStandard packaging includes safety documentation and installation guidelinesComparison with Related RX3i ModulesThe IC694DSM314 provides basic motion control capabilitiesFor advanced motion control, consider the IC695PMM335 moduleThe IC695PMM355 offers 4-axis servo motion control functionalityProfessional FAQ SectionCan I install this module while the system is powered?No, you must completely power down the system before installation or removal to prevent damage.What control modes does this motion module support?It supports both Standard Mode and Follower Mode for different motion control applications.Does this module work with all RX3i CPU models?Yes, the IC694DSM314 maintains compatibility with every CPU in the RX3i product family.What power requirements does this module have?It requires 800mA at 5V DC standalone, plus additional 500mA when using external controllers.What expansion racks support this motion module?It works in both RX3i serial expansion racks and Series 90-30 expansion rack systems.© 2025 World of PLC Limited. All rights reserved. Original Source: https://www.oiltechcontrols.com/ Technical Support Contact: [email protected] | Phone: 86 158 8020 0923 Partner: PLCDCS HUB Limited https://plcdcshub.com/ | PLC Pioneer Limited https://plc-pioneer.com/
